UL Assemblies / Wall / UL U408

UL U408
Exterior Walls, Steel Stud (Non-Load-Bearing)

  • Stc

    0

  • Fire Rating

    2 Hour

  • System Thickness

    6"
  • Stc 0
  • Fire Rating 2 Hour
  • System Thickness 6"
PDF
(278.64 KB PDF)
REVIT
(1.91 MB RVT)
CAD
(46.33 KB DWG)
Assembly Details
  • Gypsum Board
    5/8" thick Gypsum Board (UL Type USGX)
  • Steel Studs
    3-1/2" Steel Studs, 20ga. MSG., Spaced 24" O.C.
  • Insulation
    Optional Performance+® EcoBatt® Insulation
  • Gypsum Board
    3 Layers of 5/8" thick Gypsum Board (UL Type SCX)
Notes
View assembly information on UL Website.
Compatible Products
Available insulation products for UL U408.
Performance+® EcoBatt® Insulation
Quality engineered thermal and acoustical fiberglass batt insulation with innovative ECOSE® technology is ideal for floors, walls, ceilings and attics.
Applications
Attics, Ceiling, Floor, Mid-Floor, Sound Control, Walls
Thickness
2.5" - 13.75"
R-Value
R-8 - R-49
Width
11" - 24"
View Product
